INCH-POUND
The documentation and process conversion
measures necessary to comply with this revision
MIL-PRF-19500/580C
shall be completed by 13 August 2014.
13 May 2014
SUPERSEDING
MIL-PRF-19500/580B
18 February 2005
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, TRANSISTOR, PNP, SILICON AMPLIFIER,
TYPES 2N4234, 2N4235, AND 2N4236, JAN, JANTX, AND JANTXV
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for PNP, silicon, amplifier transistor. Three
levels of product assurance are provided for each device type as specified in MIL-PRF-19500.
1.2 Physical dimensions. See figure 1, TO-39.
1.3 Maximum ratings unless otherwise specified TA = +25°C.
*
PT (1)
PT (2)
IB
IC
TJ and
VCBO
VCEO
VEBO
RθJA
RθJC
Types
TA =
TC =
TSTG
+25°C
+25°C
°C/W
°C/W
°C
W
W
A dc
A dc
V dc
V dc
V dc
2N4234
1.0
6.0
0.5
1.0
-40
-40
-7.0
175
29
-65 to
2N4235
1.0
6.0
0.5
1.0
-60
-60
-7.0
175
29
+200
2N4236
1.0
6.0
0.5
1.0
-80
-80
-7.0
175
29
(1) Derate linearly 5.7 m/W°C for TA > +25°C.
(2) Derate linearly 34 m/W°C for TC > +25°C.
* Comments, suggestions, or questions on this document should be addressed to DLA Land and Maritime,
ATTN: VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to Semiconductor@dla.mil. Since contact
information can change, you may want to verify the currency of this address information using the ASSIST
Online database at https://assist.dla.mil/.
AMSC N/A
FSC 5961
