IINCH-POUND
The documentation and process conversion
measures necessary to comply with this revision
MIL-PRF-19500/592G
shall be completed by 1 June 2013.
17 April 2013
SUPERSEDING
MIL-PRF-19500/592F
2 June 2010
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, REPETITIVE AVALANCHE, FIELD EFFECT TRANSISTOR, N-CHANNEL,
SILICON, TYPES 2N7224, 2N7225, 2N7227, 2N7228, 2N7224U, 2N7225U,
2N7227U, AND 2N7228U, JAN, JANTX, JANTXV, JANS, JANHC, AND JANKC
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for an N-channel, enhancement-mode,
MOSFET, power transistor intended for use in high density power switching applications. Four levels of product
assurance are provided for each encapsulated device type as specified in MIL-PRF-19500, and two levels of product
assurance for each unencapsulated device type die, with avalanche energy ratings (EAS and EAR) and maximum
avalanche current (IAR).
1.2 Physical dimensions. See figure 1 (TO-254AA), figure 2 (TO-276AB, surface mount), and figures 3, 4, and 5
for JANHC and JANKC (die) dimensions.
1.3 Maximum ratings. (TA = +25°C, unless otherwise specified).
Type
PT (1)
PT
VGS
ID1 (2)
ID2 (2)
IS
IDM
TJ
VISO
RθJC
(3)
and
at
max
(4)
70,000
(5)
TC
TA
TC
TC
TSTG
= +25°C
= +25°C
= +25°C
= +100°C
foot
°C
°C/W
W
W
V dc
A dc
A dc
A dc
A(pk)
±20
2N7224, 2N7224U
150
4.0
34.0
21
34.0
136
-55
0.83
±20
2N7225, 2N7225U
150
4.0
27.4
17
27.4
110
to
0.83
±20
2N7227, 2N7227U
150
4.0
14.0
9
14.0
56
+150
400
0.83
±20
2N7228, 2N7228U
150
4.0
12.0
8
12.0
48
500
0.83
See notes on next page.
* Comments, suggestions, or questions on this document should be addressed to Defense Supply Center,
Columbus, ATTN: DSCC-VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to
Semiconductor@dla.mil. Since contact information can change, you may want to verify the currency of this
address information using the ASSIST Online database at https://assist.dla.mil/.
AMSC/NA
FSC 5961
