MIL-PRF-19500/627C
shall be completed by 23 October 2014.
23 July 2014
SUPERSEDING
MIL-PRF-19500/627B
24 August 2012
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, DIODE, SILICON, ULTRA-FAST RECOVERY, POWER RECTIFIER,
1N6688, 1N6689, 1N6688US, 1N6689US
JANTX, JANTXV, AND JANS
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for a silicon, ultra-fast recovery,
semiconductor power rectifier diode. Three levels of product assurance are provided for each device type as
specified in MIL-PRF-19500.
1.2 Physical dimensions. See figures 1 (similar to DO-41) and 2 (surface mount).
1.3 Maximum ratings. Unless otherwise specified, TA = +25°C.
1.3.1 Ratings applicable to all types. Ratings applicable to all Part or Identifying Numbers (PIN).
TSTG and TJ = -65°C to +175°C.
1.3.2 Ratings applicable to individual types.
Col. 1
Col. 2
Col. 3
Col. 4
Col. 5
Col. 6
Col. 7
Device type
IFSM
RθJL
RθJEC
VRWM
IO(L)
trr
at TL = +55°C
at
(2)
at
L = .375 inch
L = .375 inch
tp = 8.3 ms
(9.52 mm)
(9.52 mm)
(1)
°C/W
°C/W
V dc
A
A pk
Ns
1N6688, US
300
20
375
40
4
3.5
1N6689, US
400
20
375
40
4
3.5
Derate linearly at 267 mA/°C from +100°C to +175°C.
(1)
(2)
US devices only.
