MIL-PRF-19500/115N
1.4 Primary electrical characteristics. Primary electrical characteristics are as shown in primary test ratings (see
3.9 herein) and as follows: 3.3 V dc VZ 200 V dc. A and B suffix devices are 5 percent voltage tolerance. C suffix
devices are 2 percent voltage tolerance. D suffix devices are 1 percent voltage tolerance.
RJEC (2)
RJA (3)
RJL (1)
Type
C/W
C/W
C/W
DO-13
80
DO-41
80
DO-213AB
50
(1) L = .375 inch (9.53 mm).
(2) Junction to end-caps.
(3) See figures 6, 7, and 8 for derating curves. TA = +75C for both axial and MELF (US) on printed circuit
board (PCB), PCB = FR4 .0625 inch (1.59 mm) 1-layer 1-Oz Cu, horizontal, still air, pads (US) = .067 inch
(1.70 mm) x .105 inch (2.67 mm); pads (axial) = .092 inch (2.34 mm) diameter, strip = .030 inch (0.762 mm)
x 1 inch (25.4 mm) long, axial lead length L 187 inch (4.76 mm); RJA with a defined thermal resistance
condition included is measured at IZ = as defined in test ratings herein.
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3, 4, or 5 of this specification. This
section does not include documents cited in other sections of this specification or recommended for additional
information or as examples. While every effort has been made to ensure the completeness of this list, document
users are cautioned that they must meet all specified requirements of documents cited in sections 3, 4, or 5 of this
specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and handbooks form a
part of this document to the extent specified herein. Unless otherwise specified, the issues of these documents are
those cited in the solicitation or contract.
DEPARTMENT OF DEFENSE SPECIFICATIONS
MIL-PRF-19500
-
Semiconductor Devices, General Specification for.
DEPARTMENT OF DEFENSE STANDARDS
MIL-STD-750
-
Test Methods for Semiconductor Devices.
(Copies of these documents are available online at https://assist.daps.dla.mil/quicksearch/ or
https://assist.daps.dla.mil or from the Standardization Document Order Desk, 700 Robbins Avenue, Building 4D,
Philadelphia, PA 19111-5094.)
2.3 Order of precedence. Unless otherwise noted herein or in the contract, in the event of a conflict between the
text of this document and the references cited herein, the text of this document takes precedence. Nothing in this
document, however, supersedes applicable laws and regulations unless a specific exemption has been obtained.
3. REQUIREMENTS
3.1 General. The individual item requirements shall be as specified in MIL-PRF-19500 and as modified herein.
3.2 Qualification. Devices furnished under this specification shall be products that are manufactured by a
manufacturer authorized by the qualifying activity for listing on the applicable qualified manufacturer's list (QML)
before contract award (see 4.2 and 6.3).
2
