MIL-PRF-19500/228R
TABLE III. Groups A, B, C, and E delta measurements. 1/ 2/ 3/ 4/
Step
Inspection
Symbol
Limits
Unit
Method
Conditions
Min
Max
ĆVF2
1.
Forward voltage
4011
IF = 3.0 A dc
±0.1 V dc
pulse width = 8.3 ms
maximum
maximum; duty cycle
= 2 percent maximum.
ĆIR1
2.
Reverse current
4016
DC method; VR = rated
±50 nA dc or ±100
(see 1.3).
percent of initial value,
whichever is greater.
1/
Devices that exceed the table I, subgroup 2 limits for this test shall not be accepted.
2/
The electrical measurements for group B inspection in appendix E, table E-VIB (JAN and JANTX) of
MIL-PRF-19500 are as follows: Subgroups 3 and 6, see table III herein, steps 1 and 2.
The electrical measurements for group C inspection in appendix E, table E-VII of MIL-PRF-19500 are as follows:
3/
Subgroup 6, see table III herein, steps 1 and 2.
The electrical measurements for group E inspection in table E-IX of MIL-PRF-19500 are as follows:
4/
a. Subgroup 1, see table III herein, steps 1 and 2.
b. Subgroup 2, see table III herein, steps 1 and 2.
12
