MIL-PRF-19500/228R
TABLE I. Group A inspection ­ Continued.
Inspection 1/
Symbol
Limits
Unit
Method
Conditions
Min
Max
Subgroup 6
Forward surge
4066
IFSM = 30 A (pk); ten surges of 8.3 ms each
inspection
at 1 minute intervals, superimposed on IO =
1A
VRWM = rated (see col. 4 of 1.3.2); TA =
+55°C.
Electrical
See table 1, subgroup 2.
measurements
1/ For sampling plan, see MIL-PRF-19500.
9
