MIL-PRF-19500-251 Semiconductor Device, Transistor, Npn, Silicon, Switching, Types 2N2218, 2N2218A, 2N2218Al, 2N2219, 2N2219A, And 2N2219Al, Jan, Jantx, Jantxv, Jans, Jansm, Jansd, Jansp, Jansl, Jansr, Jansf, Jansg, And JanshThis specification covers the performance requirements for NPN, silicon, switching transistors. Four levels of product assurance are provided for each device type as specified in MIL-PRF-19500. RHA level designators "M", "D", "P", "L", "R", "F", "G", and "H" are appended to the device prefix to identify devices, which have passed RHA requirements.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16


MIL-PRF-19500/251R
* TABLE II. Group D inspection - Continued.
Inspection 1/ 2/ 3/
MIL-STD-750
Limit
Unit
Method
Conditions
Symbol
Min
Max
Subgroup 1 - Continued.
Forward-current transfer ratio
3076
[hFE3] 5/
VCE = 10 V dc; IC = 10 mA dc;
pulsed (see 4.5.1)
2N2218
[17.5]
2N2219
[37.5]
2N2218A, 2N2218AL
[20]
2N2219A, 2N2219AL
[50]
Forward-current transfer ratio
3076
[hFE4] 5/
VCE = 10 V dc; IC = 150 mA dc;
pulsed (see 4.5.1)
2N2218
[20]
120
2N2219
[50]
300
2N2218A, 2N2218AL
[20]
120
2N2219A, 2N2219AL
[50]
300
Forward-current transfer ratio
3076
[hFE5] 5/
VCE = 10 V dc; IC = 500 mA dc;
pulsed (see 4.5.1)
2N2218
[10]
2N2219
[15]
2N2218A, 2N2218AL
[10]
2N2219A, 2N2219AL
[15]
Collector-emitter saturation
3071
IC = 150 mA dc; IB = 15 mA dc;
VCE(sat)1
voltage
pulsed (see 4.5.1)
2N2218, 2N2219
0.46
V dc
2N2218A, 2N2219A
0.35
V dc
2N2218AL, 2N2219AL
0.35
V dc
Collector-emitter saturation
3071
IC = 500 mA dc; IB = 50 mA dc;
VCE(sat)2
voltage
pulsed (see 4.5.1)
2N2218, 2N2219
1.84
V dc
2N2218A, 2N2219A
1.15
V dc
2N2218AL, 2N2219AL
1.15
V dc
Base-emitter saturation voltage
3066
Test condition A; IC = 150 mA dc;
VBE(sat)1
IB = 15 mA dc; pulsed (see 4.5.1)
2N2218, 2N2219
0.6
1.50
V dc
2N2218A, 2N2219A
0.6
1.38
V dc
2N2218AL, 2N2219AL
0.6
1.38
V dc
3066
Base-emitter saturation voltage
Test condition A; IC = 500 mA dc;
VBE(sat)2
IB = 50 mA dc; pulsed (see 4.5.1)
2N2218, 2N2219
3.0
V dc
2N2218A, 2N2219A
2.3
V dc
2N2218AL, 2N2219AL
2.3
V dc
See footnotes at end of table.
