MIL-PRF-19500/291U
* TABLE I. Group A inspection.
Inspection 1/
MIL-STD-750
Symbol
Limit
Unit
Method
Conditions
Min
Max
Subgroup 1 2/
2071
Visual and mechanical
inspection 3/
Solderability 3/ 4/
2026
n = 15 leads, c = 0
Resistance to solvents
1022
n = 15 devices, c = 0
3/ 4/ 5/
Temp cycling 3/ 4/
1051
Test condition C, 25 cycles. n = 22
devices, c = 0
Hermetic seal 4/
1071
n = 22 devices, c = 0
Fine leak
Gross leak
Electrical measurements
Table I, subgroup 2
4/
Precondition TA = +250°C at t = 24 hours
Bond strength 3/ 4/
2037
or TA = +300°C at t = 2 hours
n = 11 wires, c = 0
Decap internal visual
2075
n = 4 devices, c = 0
(design verification) 4/
Subgroup 2
°C/W
Thermal impedance
3131
See 4.3.3
ZθJX
µA dc
Collector to base cutoff
3036
10
Bias condition D; VCB = 60 V dc
ICBO1
current
µA dc
Cutoff current, emitter to
3061
10
Bias condition D; VEB = 5 V dc
IEBO1
base
Breakdown voltage,
3011
60
V dc
Bias condition D; IC = 10 mA dc; pulsed
V(BR)CEO
collector to emitter
(see 4.5.1)
Collector to emitter
3041
50
nA dc
Bias condition C; VCE = 50 V dc
ICES
cutoff current
Collector to base cutoff
3036
10
nA dc
Bias condition D; VCB = 50 V dc
ICBO2
current
Emitter to base cutoff
3061
50
nA dc
Bias condition D; VEB = 4 V dc
IEBO2
current
See footnotes at end of table.
15
