MIL-PRF-19500/291U
*
4.4.3.2 Group C inspection, table E-VII (JAN, JANTX, and JANTXV) of MIL-PRF-19500.
Subgroup
Method
Condition
*
C2
2036
Test condition E, (not applicable for UA, UB, UBC, UBN, and UBCN devices).
C5
3131
C6
Not applicable.
4.4.3.3 Group C sample selection. Samples for steps in group C shall be chosen at random from any inspection
lot containing the intended package type and lead finish procured to the same specification which is submitted to and
passes table I tests for conformance inspection. Testing of a subgroup using a single device type enclosed in the
intended package type shall be considered as complying with the requirements for that subgroup.
* 4.4.4 Group D inspection. Conformance inspection for hardness assured JANS and JANTXV types shall include
the group D tests specified in table II herein. These tests shall be performed as required in accordance with
MIL-PRF-19500 and method 1019 of MIL-STD-750, for total ionizing dose or method 1017 of MIL-STD-750 for
neutron fluence as applicable (see 6.2 herein), except group D, subgroup 2 may be performed separate from other
subgroups. Alternate package options may also be substituted for the testing provided there is no adverse effect to
the fluence profile.
4.4.5 Group E inspection. Group E inspection shall be conducted in accordance with the conditions specified for
subgroup testing in appendix E, table E-IX of MIL-PRF-19500 and as specified in table III herein. Electrical
measurements (end-points) shall be in accordance with table I, subgroup 2 herein. Delta measurements shall be in
accordance with the applicable steps of 4.5.3.
4.5 Method of inspection. Methods of inspection shall be as specified in the appropriate tables and as follows.
4.5.1 Pulse measurements. Conditions for pulse measurement shall be as specified in section 4 of
MIL-STD-750.
4.5.2 Input capacitance. This test shall be conducted in accordance with method 3240 of MIL-STD-750, except
the output capacitor shall be omitted.
4.5.3 Delta requirements. Delta requirements shall be as specified below:
Step
Inspection
MIL-STD-750
Symbol
Limit
Method
Conditions
ĆICB02
1
Collector-base cutoff
3036
Bias condition D,
100 percent of initial
current
value or 10 nA dc,
VCB = 50 V dc
(1)
whichever is greater.
±25 percent change
ĆhFE4
2
Forward current
3076
VCE = 10 V dc;
transfer ratio
from initial reading.
(1)
IC = 150 mA dc;
pulsed see 4.5.1
(1) Devices which exceed the table I limits for this test shall not be accepted.
