MIL-PRF-19500/291U

TABLE III. Group E inspection (all quality levels) - for qualification only.

Inspection

MIL-STD-750

Qualification

Method

Conditions

Subgroup 1

45 devices

c=0

Temperature cycling

1051

Test condition C, 500 cycles.

(air to air)

Hermetic seal

1071

Fine leak

Gross leak

Electrical measurements

See table I, subgroup 2 and 4.5.3 herein.

Subgroup 2

45 devices

c=0

1037

Intermittent life

VCB = 10 V dc, 6,000 cycles. Adjust device current, or

power, to achieve a minimum ĆTJ of 100�C.

Electrical measurements

See table I, subgroup 2 and 4.5.3 herein.

Subgroup 4

15 devices

Thermal resistance

3131

c=0

RθJSP(IS) may be calculated but shall be measured once

in the same package with a similar die size to confirm

calculations (may apply to multiple slash sheets).

RθJSP(AM) need be calculated only.

Thermal impedance

See MIL-PRF-19500, table E-IX, group E, subgroup 4.

Sample size

curves

N/A

Subgroup 5

Not applicable

Subgroup 6

11 devices

ESD

1020

Subgroup 8

45 devices

c=0

Reverse stability

1033

Condition B.
