MIL-PRF-19500-304 Semiconductor Device, Diode, Silicon, Power Rectifier, Fast-Recovery Types 1N3885, 1N3886, 1N3888, 1N3890, 1N3891, 1N3893, 1N3890R, 1N3891R, 1N3893R And A-Versions Jan, Jantx, Jantxv, Jans, Janhc And JankcThis specification covers the performance requirements for 12 and 20 ampere, silicon fast recovery, power, rectifier diodes. Four levels of product assurance are provided for each encapsulated device type as specified in MIL-PRF-19500, and two levels of product assurance for each unencapsulated device type.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15


. . . . . . .
MIL-PRF-19500/304E
* TABLE II. Group E inspection (all quality levels) for qualification and requalification only.
MIL-STD-750
Inspection 1/
Sampling plan
Method
Conditions
Subgroup 1
45 devices, c = 0
0°C to 100°C, 100 cycles.
Thermal shock
1056
Hermetic seal
1071
Electrical
See table I subgroup 2 and table III herein.
measurements
Subgroup 2
45 devices, c = 0
Steady-state dc
1038
Condition A; 1,000 hrs.
blocking life
Electrical
See table I subgroup 2 and table III herein. (Except ZθJX
measurements
need not be performed.)
Subgroup 4
Thermal impedance
See MIL-PRF-19500.
curves
Subgroup 5
22 devices, c = 0
Barometric pressure,
1001
Hg = rated Hg (see 1.3), t = 60 s, while the test is being
reduced (altitude
performed, IR shall be monitored and shall not exceed 25
operation)
µA dc. TC = 25°C.
Subgroup 6 2/
11 devices, c = 0
ESD
1020
Subgroup 8
45 devices
Peak reverse power
4065
Peak reverse power (PRM)= shall be characterized by the
supplier and this data shall be available to the
Government. Test shall be performed on each sublot.
Electrical
During the PRM test, the voltage (VBR) shall be monitored
measurement
to verify it has not collapsed. Any collapse in VBR during
or after the PRM test, or rise in leakage current (IR) after
the test that exceeds IR1 in table I, shall be considered a
failure to that level of applied PRM. Progressively higher
levels of PRM shall be applied until failure occurs on all
devices within the chosen sample size to characterize
each sublot.
Subgroup 10
22 devices, c = 0
Forward surge
4066
Condition A, ten surges of 8.3 ms each at 1 minute
intervals, VRWM = rated VRWM (see 1.3). TC = +100°C.
Non-A version devises, IFS = 150 A; IO = 12 A dc; A
version devises, IFS = 225 A; IO = 20 A dc.
12
