MIL-PRF-19500/304E

TABLE III. Groups B and C delta electrical measurements. 1/ 2/ 3/ 4/ 5/

MIL-STD-750

Limits

Step

Inspection

Symbol

Unit

Method

Conditions

Min

Max

ĆVF

Thermal response

3101

mV dc

See 4.3.2, RθJC = rated RθJC

(see 1.4)

ĆVF3

Forward voltage

4011

+50 mV dc maximum

IF = 50 mA dc

change from previous to

post intermittent life and

thermal shock

measurement tests (JANS

only).

100 percent or �5 �A,

ĆIR1

Reverse current

4016

DC method VR = rated VR (dc)

(whichever is greater)

(see 1.3)

change from initial group A

reading.

1/ Devices which exceed the group A limits for this test shall be rejected.

2/ The delta measurements for table E-VIa (JANS) of MIL-PRF-19500 are as follows:

a. Subgroup 3, see table III herein, steps 1 and 2.

b. Subgroup 4, see table III herein, steps 1 and 2.

c. Subgroup 5, see table III herein, step 3.

3/ The delta measurements for table E-VIb (JAN, JANTX, and JANTXV) of MIL-PRF-19500 are as follows:

a. Subgroup 3, see table III herein, step 1.

4/ The delta electrical measurements for table E-VII of MIL-PRF-19500 are as follows:

a. Subgroup 2, see table III herein, step 1.

b. Subgroup 6, see table III herein, steps 1 and 3 (JANS); and step 1 (JAN, JANTX, and JANTXV).

5/ The delta electrical measurements for table E-IX of MIL-PRF-19500 are as follows:

a. Subgroup 1, see table III herein, step 1.

b. Subgroup 2, see table III herein, step 3.
