MIL-PRF-19500/348F
shall be completed by 16 May 2005.
15 February 2005
SUPERSEDING
MIL-PRF-19500/348E
25 July 1999
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, TRANSISTOR, PNP, SILICON, SWITCHING,
TYPES 2N3467, 2N3467L, 2N3468, 2N3468L, JAN, JANTX, JANTXV, AND JANS
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
* The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for PNP silicon switching transistors. Four
levels of product assurance is provided for the device type as specified in MIL-PRF-19500.
1.2 Physical dimensions. See figure 1 (TO-39 and TO-5).
* 1.3 Maximum ratings. (T = +25°C unless otherwise specified).
A
RΘJC
RΘJA
VCBO
VCEO
PT (1)
PT (2)
VEBO
IC
TJ
and
TA =
TC =
TSTG
2N3467
2N3468
2N3467
2N3468
+25°C
+25°C
2N3467L
2N3468L
2N3467L
2N3468L
°C/W
°C
°C/W
V dc
V dc
V dc
V dc
V dc
A dc
W
W
1.0
5.0
40
50
40
50
5.0
1.0
175
30
-55 to
+200
(1) See figure 2.
(2) See figure 3.
