MIL-PRF-19500/348F
1.4 Primary electrical characteristics.
Limits
hFE2 (1)
hFE3 (1)
VCE(sat)2
VCE = 1.0 V dc
VCE = 1.0 V dc
VCE = 5.0 V dc
VCE = 5.0 V dc
IC = 500 mA dc
IC = 500 mA dc
IC = 500 mA dc
IC = 1.0 A dc
IC = 1.0 A dc
IB = 50 mA dc
2N3467
2N3468
2N3467
2N3468
2N3467L
2N3468L
2N3467L
2N3468L
V dc
Min
40
25
40
25
Max
0.6
120
75
Cobo
fT
ton
toff
Limits
VCB = 10 V dc
VCE = 10 V dc
IC = 500 mA dc
IC = 500 mA dc
IE = 0;
IC = 50 mA dc
IB = 50 mA dc
IB = 50 mA dc
100 kHz ≤ f ≤ 1 MHz
f = 100 MHz
2N3468
2N3467
2N3467L
2N3468L
Mhz
Mhz
ns
ns
pF
175
150
Min
25
500
500
40
90
Max
(1) Pulsed (see 4.5.1).
2. APPLICABLE DOCUMENTS
* 2.1 General. The documents listed in this section are specified in sections 3, 4, or 5 of this specification. This
section does not include documents cited in other sections of this specification or recommended for additional
information or as examples. While every effort has been made to ensure the completeness of this list, document
users are cautioned that they must meet all specified requirements of documents cited in sections 3, 4, or 5 of this
specification, whether or not they are listed.
2.2 Government documents.
* 2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and handbooks form a
part of this document to the extent specified herein. Unless otherwise specified, the issues of these documents are
those cited in the solicitation or contract.
DEPARTMENT OF DEFENSE SPECIFICATIONS
MIL-PRF-19500
-
Semiconductor Devices, General Specification for.
DEPARTMENT OF DEFENSE STANDARDS
MIL-STD-750
-
Test Methods for Semiconductor Devices.
* (Copies of these documents are available online at https://assist.daps.dla.mil/quicksearch/ or
https://assist.daps.dla.mil or from the Standardization Document Order Desk, 700 Robbins Avenue, Building 4D,
Philadelphia, PA 19111-5094.)
2
