MIL-PRF-19500/384H
TABLE II. Groups B and E delta measurements. 1/ 2/
Step
Inspection
Symbol
Limit
Unit
Method
Conditions
Min
Max
ĆICEX1
1.
Collector to emitter
3041
Bias condition A;
±100 percent of initial
cutoff current
VBE = -1.5 V dc
value or ±0.1 mA dc,
whichever is greater.
2N3584
VCE = 300 V dc
2N3585
VCE = 400 V dc
ĆhFE1
2.
Forward-current
3076
VCE = 10 V dc; IC = 1 A dc;
±25 percent change
transfer ratio
pulsed (see 4.5.1)
from initial value.
The delta measurements for table E-VIB (JAN, JANTX, and JANTXV) of MIL-PRF-19500 are subgroup 3, see
1/
table II herein, all steps.
The delta measurements for table E-VII of MIL-PRF-19500 are subgroup 6, see table II herein, all steps.
2/
3/
The delta measurements for table E-IX of MIL-PRF-19500 are: Subgroups 1 and 2, see table II herein, all steps.
