MIL-PRF-19500/384H

* TABLE III. Group E inspection (all quality levels) � for qualification or re-qualification only.

Inspection

Sample

MIL-STD-750

Method

Conditions

plan

Subgroup 1

45 devices

c=0

Temperature cycling

1051

Test condition C, 500 cycles.

(air to air)

Hermetic seal

1071

Fine leak

Gross leak

Delta measurements

See table II herein.

Subgroup 2

45 devices

c=0

Test temperature = +125�C; VCB = 30 V dc; T =

Blocking life

1048

1,000 hours.

Delta measurements

See table II herein.

Subgroup 4

Sample size

N/A

Thermal impedance

See MIL-PRF-19500.

curves

Subgroup 5

3 devices

c=0

Normal mounting pressure = 8 mm Hg �2 mm

Barometric pressure

1001

Hg for 60 seconds (minimum). ICBO at 320 V dc

and IC = 500 �A maximum.

Subgroup 8

45 devices

c=0

Reverse stability

1033

Condition A for 2N3585, condition B for 2N3584.
