MIL-PRF-19500-396 Semiconductor Device, Transistor, Pnp, Silicon, Switching, Types 2N3762, 2N3762L, 2N3762U4, 2N3762Ua, 2N3763, 2N3763L, 2N3763U4, 2N3763Ua, 2N3764, And 2N3765, Jan, Jantx, Jantxv, Jans, Jansm, Jansd, Jansp, Jansl, Jansr, Jansf, Jansg, Jansh Janhca, Jankca, Jankcam, Jankcad, Jankcap, Jankcal, Jankcar, Jankcaf, Jankcag, And JankcahThis specification covers the performance requirements for PNP silicon switching transistors. Four levels of product assurance are provided for each encapsulated device type as specified in MIL-PRF-19500 and two levels of product assurance are provided for each unencapsulated device type. RHA level designators "M", "D", "P", "L", "R", "F", "G", and "H" are appended to the device prefix to identify devices, which have passed RHA requirements.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15

MIL-PRF-19500/396L

TO-5, 39

Dimensions

Symbol

Inches

Millimeters

Note

Min

Max

Min

Max

.305

.335

7.75

8.51

.240

.260

6.10

6.60

.335

.370

8.51

9.40

.200 TP

5.08 TP

.016

.019

0.41

0.48

8,9

See note 14

.016

.019

0.41

0.48

8,9

.050

1.27

8,9

.250

6.35

8,9

.100

2.54

.030

0.76

.029

.045

0.74

1.14

3,4

.028

.034

0.71

0.86

.010

0.25

45� TP

NOTES:

1. Dimensions are in inches.

2. Millimeters are given for general information only.

3. Beyond r (radius) maximum, TW shall be held for a minimum length of .011 (0.28 mm).

4. Dimension TL measured from maximum HD.

5. Body contour optional within zone defined by HD, CD, and Q.

6. CD shall not vary more than .010 inch (0.25 mm) in zone P. This zone is controlled for automatic handling.

7. Leads at gauge plane .054 +.001 -.000 inch (1.37 +0.03 -0.00 mm) below seating plane shall be within .007

inch (0.18 mm) radius of true position (TP) at maximum material condition (MMC) relative to tab at MMC.

The device may be measured by direct methods or by gauging procedure.

8. Dimension LU applies between L1 and L2. Dimension LD applies between L2 and LL minimum. Diameter

is uncontrolled in and beyond LL minimum.

9. All three leads.

10. The collector shall be internally connected to the case.

11. Dimension r (radius) applies to both inside corners of tab.

12. In accordance with ASME Y14.5M, diameters are equivalent to Φx symbology.

13. Lead 1 = emitter, lead 2 = base, lead 3 = collector.

14. For L-suffix or non-S-suffix devices (T0-5), dimension LL = 1.5 inches (38.10 mm) min. and 1.75 inches

(44.45 mm) max. For S-suffix types (T0-39), dimension LL = .5 inch (12.70 mm) min. and .750 inch

(19.05 mm) max.

FIGURE 1. Physical dimensions 2N3762L and 2N3763L (TO-5), 2N3762 and 2N3763 (TO-39).
