MIL-PRF-19500/408K
TABLE I. Group A inspection Continued.
Limit
Inspection 1/
Symbol
Unit
Method
Conditions
Min
Max
Subgroup 5
TC = +25°C; t ≥ 1 s; 1 cycle;
Safe operating area
3051
(continuous dc)
(see figure 5)
VCE = 15 V dc; IC = 10 A dc
Test 1
VCE = 40 V dc; IC = 3.75 A dc
Test 2
Test 3
VCE = 55 V dc; IC = 0.9 A dc
2N3715
VCE = 65 V dc; IC = 0.9 A dc
2N3716
TA = +25°C; IC = 10 A dc;
Safe operating area
3053
(switching) (clamped
VCC = 15 V dc;
inductive)
2N3715
Clamp voltage = 60 V dc
2N3716
Clamp voltage = 80 V dc
tp approximately 1.0 ms (vary to
Test 1
obtain IC);
RBB1 = 5Ω; VBB1 = 8 V dc;
RBB2 = 4Ω; VBB2 = 0; VCC = 15 V
dc; IC = 5 A dc; L = 4 mH; Q ≥ 100
at 1 kHz; .05 ohms, 20 A dc;
(Stanford Miller CK-20 or
equivalent)
tp approximately 2.2 ms (vary to
Test 2
obtain IC);
RBB1 = 5Ω; VBB1 = 8 V dc;
RBB2 = 4Ω; VBB2 = 0; VCC = 15 V
dc; IC = 2.2 A dc; L = 20 mH;
Q ≥ 6,000 at 10 kHz; 0.22 ohms,
12.5 A dc; (two Stancor C-2688 in
series or equivalent)
Electrical measurements
See subgroup 2 of this table
Subgroups 6 and 7
Not applicable
1/
For sampling plan, see MILPRF19500.
2/
This test required for the following end-point measurements only:
Group B, subgroups 3, 4, and 5 (JANS).
Group B, subgroups 2 and 3 (JAN, JANTX, and JANTXV).
Group C, subgroup 2 and 6.
Group E, subgroup 1.
11
