MIL-PRF-19500-415 Semiconductor, Device, Transistor, Npn, Silicon, High-Power Types 2N2812 And 2N2814 Jan, Jantx, And JantxvThis specification covers the performance requirements for NPN, silicon, high-power transistors. Three levels of product assurance are provided for each encapsulated device type as specified in MIL-PRF-19500.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15


MIL-PRF-19500/415A
Maximum safe operating area (forward bias, continuous DC)
2N2812 and 2N2814, Tc=100C
10
1
2N2814
0.1
2N2812
0.01
1
10
100
Voltage (V)
NOTE: TC = +100°C
FIGURE 3. Maximum safe operating area (forward bias, continuous DC).
12
