MIL-PRF-19500/434E

* TABLE IV. Group E inspection.

Inspection

Sampling plan

Method

Conditions

Subgroup 1

45 devices

c=0

500 cycles, condition C, -55�C to +175�C.

Temperature cycling

1051

Electrical measurements

See table III. Steps 1, 2, 3, 4, and 5.

Subgroup 2

22 devices

c=0

1,000 hours. See 4.5.1.

Life test

Electrical measurements

See table III, Steps 1, 2, 3, 4, and 5.

Subgroup 4

Not applicable

Subgroup 5

Not applicable

Subgroup 6

See 4.5.2. IPP shall be characterized by the supplier

Peak pulse current

and this data shall be available to the government.

Test shall be performed on each low and high voltage

device for each structurally identical grouping. Test to

failure.

Electrical measurements

See table III, steps 1, 2, 3, 4, and 5.

Subgroup 7

3 devices,

c=0

Soldering heat

2031
