MIL-PRF-19500-435 Semiconductor Device, Diode, Silicon, Low-Noise Voltage Regulator, Types 1N4099-1 Through 1N4135-1, 1N4614-1 Through 1N4627-1, 1N4099Ur-1 Through 1N4135Ur-1, 1N4614Ur-1 Through 1N4627Ur-1, \(Ub, Ub2, Ub2R, Ubca, Ubd, And Ubcc\), C And D Tolerance Suffix Devices, Jan, Jantx, Jantxv, Jans, Janhc, And JankcThis specification covers the performance requirements for 500 milliwatt, silicon, low-noise, voltage regulator diodes with voltage tolerances of 5 percent, 2 percent, and 1 percent. Four levels of product assurance are provided for each encapsulated device type as specified in MIL-PRF-19500, and two levels of product assurance for each unencapsulated device type \(die\). For JANHC and JANKC quality levels see 6.5.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15


MIL-PRF-19500/435M
* TABLE III. Test ratings, primary electrical characteristics. 1/
Col 1
Col 2
Col 3
Col 4
Col 5
Col 6
Col 7
Col 8
Col 9
Col 10
αVZ
VZ
IR
ZZT
IZSM
IZSM
VR
IR
IZPCB
2/
ND
T1 = +25°C
at
max
(surge)
(surge)
nom
+150°C
UB
T2 = +125°C
___
µV/ √ Hz
µA dc
µA dc
%/°C
Volts
ohms
mA
mA
Volts
mA
1N4614-1
1.8
10.0
1,200
1,600
500
1.0
3.5
-0.075
1
120
1N4615-1
2.0
8.0
1,250
1,500
469
1.0
2.5
-0.075
1
110
1N4616-1
2.2
6.0
1,300
1,350
422
1.0
2.0
-0.075
1
100
1N4617-1
2.4
4.0
1,400
1,250
390
1.0
1.0
-0.075
1
95
1N4618-1
2.7
2.0
1,500
1,100
343
1.0
0.5
-0.075
1
90
1N4619-1
3.0
1.0
1,600
1,025
320
1.0
0.4
-0.075
1
87
1N4620-1
3.3
7.0
1,650
950
297
1.5
3.5
-0.075
1
85
1N4621-1
3.6
10.0
1,700
875
273
2.0
3.5
-0.065
1
83
1N4622-1
3.9
5.0
1,650
825
258
2.0
2.5
-0.060
1
80
1N4623-1
4.3
4.0
1,600
800
250
2.0
2.0
-0.050
1
77
1N4624-1
4.7
10.0
1,550
750
234
3.0
5.0
+.020,-.050
1
75
1N4625-1
5.1
10.0
1,500
725
227
3.0
5.0
+.030,-.045
2
70
1N4626-1
5.6
10.0
1,400
700
219
4.0
5.0
+.040,-.020
4
65
1N4627-1
6.2
10.0
1,200
650
203
5.0
5.0
+.050,-.010
5
61
1N4099-1
6.8
5.0
200
650
203
5.2
1.0
+.060
40
56
1N4100-1
7.5
5.0
200
650
203
5.7
1.0
+.065
40
51
1N4101-1
8.2
5.0
200
650
203
6.3
0.5
+.070
40
46
1N4102-1
8.7
5.0
200
650
203
6.7
0.5
+.075
40
44
1N4103-1
9.1
5.0
200
650
203
7.0
0.5
+.080
40
42
1N4104-1
10.0
5.0
200
650
203
7.6
0.5
+.080
40
38
1N4105-1
11.0
5.0
200
590
184
8.5
0.05
+.080
40
35
1N4106-1
12.0
5.0
200
540
169
9.2
0.05
+.080
40
32
1N4107-1
13.0
5.0
200
500
156
9.9
0.05
+.080
40
29
1N4108-1
14.0
5.0
200
464
145
10.7
0.05
+.085
40
27
1N4109-1
15.0
5.0
100
433
135
11.4
0.05
+.085
40
25
