MIL-PRF-19500-439 Semiconductor Device, Transistor, Npn, Silicon, High-Power, Types 2N5038 And 2N5039, Jan, Jantx, Jantxv, Jans, Janhc, And JankcThis specification covers the performance requirements for NPN silicon, high-power transistors for use in high-speed power-switching applications. Four levels of product assurance are provided for each encapsulated device type as specified in MIL-PRF-19500, and two levels of product assurance are provided for each unencapsulated device type.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15


MIL-PRF-19500/439H
Maxim038,Thermal Tmpe25°C e
2N5 um 2N5039 I L = danc
Maximum Thermal Impedance Plots
10
1
0.1
0.01
0.001
0.000001
0.00001
0.0001
0.001
0.01
0.1
1
10
Time (s)
RΘJX = 1.25°C/W
ZΘJX = 0.6°C/W at 10ms
ZΘJX = 0.75°C/W at 30ms
FIGURE 4. Thermal impedance.
14
