MIL-PRF-19500/448F
1.4 Primary electrical characteristics TA = +25°C unless otherwise stated.
Limit
hFE1 (1)
hFE3 (1)
VBE(SAT)2 (1)
VCE(SAT)3 (1)
Cobo
|hfe|
VCE = 5 V dc
VCE = 5 V dc
IC = 500 mA
IC = 500 mA dc
VCB = 10 V dc
VCE = 20 V dc
IC = 100 µA dc
IC = 150 mA
dc
IB = 50 mA dc
IE = 0 mA dc
IC = 50 mA dc
100 kHz ≤ f ≤1 MHz
IB = 50 mA dc
dc
f = 100 MHz
V dc
V dc
pF
Min
75
100
2.0
0.85
Max
300
6.0
1.20
0.5
20
(1) Pulsed (see 4.5.1).
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3, 4, or 5 of this specification. This
section does not include documents cited in other sections of this specification or recommended for additional
information or as examples. While every effort has been made to ensure the completeness of this list, document
users are cautioned that they must meet all specified requirements of documents cited in sections 3, 4, or 5 of this
specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and handbooks form a
part of this document to the extent specified herein. Unless otherwise specified, the issues of these documents are
those cited in the solicitation or contract.
DEPARTMENT OF DEFENSE SPECIFICATIONS
MIL-PRF-19500
-
Semiconductor Devices, General Specification for.
DEPARTMENT OF DEFENSE STANDARDS
MIL-STD-750
-
Test Methods for Semiconductor Devices.
* (Copies of these documents are available online at https://quicksearch.dla.mil or https://assist.dla.mil or from the
Standardization Document Order Desk, 700 Robbins Avenue, Building 4D, Philadelphia, PA 19111-5094.)
2.3 Order of precedence. Unless otherwise noted herein or in the contract, in the event of a conflict between the
text of this document and the references cited herein, the text of this document takes precedence. Nothing in this
document, however, supersedes applicable laws and regulations unless a specific exemption has been obtained.
