MIL-PRF-19500-448 Semiconductor Device, Transistor, Pnp, Silicon, Low-Power, Type 2N4405, 2N4405Ua, And 2N4405Ub, Jan And JantxThis specification covers the performance requirements for PNP, silicon, low-power transistors. Two levels of product assurance are provided for each device type as specified in MIL-PRF-19500.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15

MIL-PRF-19500/448F

Dimensions

Symbol

Inches

Millimeters

Notes

Min.

Max.

Min.

Max.

.305

.335

7.75

8.51

.24

.26

6.1

6.6

.335

.37

8.51

9.4

.200 TP

5.08 TP

.016

.021

.41

.53

2, 5

.500

.750

12.70 19.05

.016

.019

.41

.48

3, 5

.050

1.27

.250

6.35

.100

2.54

.040

1.02

.007

.18

.029

.045

.74

1.14

.028

.034

.71

.86

45� TP

NOTES:

1. Dimensions are in inches.

2. Millimeters are given for general information only.

3. Measured in the zone beyond .250 (6.35) from the seating plane.

4. Measured in the zone .050 (1.27 mm) and .250 (6.35) from the seating plane.

5. Measured from the maximum diameter of the actual case.

6. All three leads.

7. In accordance with ASME Y14.5M, diameters are equivalent to φx symbology.

8. Lead 1 is the emitter, lead 2 is the base, and lead 3 is the collector, which is electrically connected to the

case.

FIGURE 1. Physical dimensions for 2N4405 (similar to TO-39).
