MIL-PRF-19500/474G

4.3 Screening (JANS, JANTXV, and JANTX levels). Screening shall be in accordance with table E-IV of

MIL-PRF-19500 and as specified herein. Specified electrical measurements shall be made in accordance with table I

herein. Devices that exceed the limits of table I herein shall not be acceptable.

Screen

Measurements

(see table E-IV of

JANS level

JANTX and JANTXV levels

MIL-PRF-19500)

Method 2010 of MIL-STD-883,

condition B

condition B (JANTXV only)

Optional

Not applicable

IR1 and VF1

See 4.3.1

Subgroups 2 and 3 of table I herein;

Subgroup 2 of table I herein;

ΔIR1 = 100 percent ofinitial reading

ΔIR1 = 100 percent ofinitial reading or

or 10 nA dc, whichever is greater;

�25 nA dc, whichever is greater;

ΔVF1 = �25 mV dc of initial reading.

ΔVF1 = �30 mV dc of initial reading.

Required

4.3.1 Power burn-in conditions. Power burn-in conditions are as follows (see 4.5.7): TA = +150�C. Time = 72

hours minimum. VR = 50 V dc for 1N5768, 1N5770, 1N5772, 1N5774, 1N6496, 1N6506, 1N6507, 1N6508, and

1N6509. VR = 60 V dc for 1N6100, 1N6101, 1N6510, and 1N6511.

4.4 Conformance inspection. Conformance inspection shall be in accordance with MIL-PRF-19500 and as

specified herein.

4.4.1 Group A inspection. Group A inspection shall be conducted in accordance with table E-V of

MIL-PRF-19500, table I herein, and as specified herein. Electrical measurements (end-points) shall be in

accordance with table I, subgroup 2 herein.

4.4.2 Group B inspection. Group B inspection shall be conducted in accordance with the conditions specified for

subgroup testing in table E-VIa (JANS) and table E-VIb (JAN, JANTX, JANTXV) of MIL-PRF-19500 and as specified

herein. Electrical measurements (end-points) and delta requirements shall be in accordance with table I, subgroup

2 herein.

4.4.2.1 Group B inspection, table E-VIa (JANS) of MIL-PRF-19500.

Method

Conditions

Subgroup

TA = +150�C each diode DC blocking, VR = 50 V dc.

1027

4.4.2.2 Group B inspection, table E-VIb (JANTX and JANTXV) of MIL-PRF-19500.

Method

Conditions

Subgroup

DC blocking; TA = +150�C; VR = 50 V dc.

1027
