MIL-PRF-19500/476F

CERAMIC

Dimensions

Symbol

Inches

Millimeters

Note

Min

Max

Min

Max

.046

.056

1.17

1.42

.115

.128

2.92

3.25

.085

.108

2.16

2.74

.128

3.25

.108

2.74

LL1

.022

.038

0.56

0.96

LL2

.017

.035

0.43

0.89

LS1

.036

.040

0.91

1.02

LS2

.071

.079

1.81

2.01

.016

.024

0.41

0.61

.008

.203

.012

.305

.022

.559

NOTES:

1. Dimensions are in inches.

2. Millimeters are given for general information only.

3. Hatched areas on package denote metallized areas (tungsten with gold plating 60 micro inches min over 80

micro inches min nickel.

4. Pad 1 = drain, Pad 2 = source, Pad 3 = gate, Pad 4 = shielding connected to the lid.

FIGURE 2. Physical dimensions, surface mount (UB version).
