MIL-PRF-19500/476F
* TABLE I. Group A inspection.
Inspection 1/
Symbol
Unit
Limits
Method
Conditions
Min
Max
Subgroup 1
2071
Visual and mechanical
examination
Subgroup 2
Bias condition C; IG = 1.0 µA dc;
3401
V(BR)GSS
30
V dc
Gate to source breakdown
voltage
VDS = 0
Gate reverse current
3411
Bias condition C; VGS = 20 V dc;
IGSS
500
pA dc
VDS = 0
Drain cutoff current
3413
Bias condition A
ID(off)1
2N5114, 2N5114UB
VDS = -15 V dc; VGS = 12 V dc
-500
pA dc
2N5115, 2N5115UB
VDS = -15 V dc; VGS = 7.0 V dc
-500
pA dc
2N5116, 2N5116UB
VDS = -15 V dc; VGS = 5.0 V dc
-500
pA dc
Zero-gate-voltage drain
3413
Bias condition C; VDS to be pulsed
IDSS
current
see 4.5.1
2N5114, 2N5114UB
VDS = -18 V dc; VGS = 0
-30
-90
mA dc
2N5115, 2N5115UB
VDS = -15 V dc; VGS = 0
-15
-60
mA dc
2N5116, 2N5116UB
VDS = -15 V dc; VGS = 0
-5.0
-25
mA dc
Drain to source on voltage
3405
Bias condition B
VDS(on)
*
2N5114, 2N5114UB
ID = -15 mA dc; VGS = 0
-1.3
V dc
2N5115, 2N5115UB
ID = -7.0 mA dc; VGS = 0
-0.8
V dc
2N5116, 2N5116UB
ID = -3.0 mA dc; VGS = 0
-0.6
V dc
Gate to source cutoff
3403
VGS(off)
voltage
2N5114, 2N5114UB
VDS = -15 V dc; ID = -1.0 nA dc
5.0
10
V dc
2N5115, 2N5115UB
VDS = -15 V dc; ID = -1.0 nA dc
3.0
6.0
V dc
2N5116, 2N5116UB
VDS = -15 V dc; ID = -1.0 nA dc
1.0
4.0
V dc
Small-signal drain to source
3423
VGS = 0; ID = -1 mA dc
rds(on)1
on resistance
Ω
2N5114, 2N5114UB
75
Ω
2N5115, 2N5115UB
100
Ω
2N5116, 2N5116UB
175
Small-signal drain to source
3423
VGS = 0; ID = 0; f = 1 kHz
rds(on)2
on resistance
Ω
2N5114, 2N5114UB
75
Ω
2N5115, 2N5115UB
100
Ω
2N5116, 2N5116UB
175
See footnote at end of table.
8
