MIL-PRF-19500/476F
4 VERIFICATION
4.1 Classification of inspections. The inspection requirements specified herein are classified as follows:
a. Qualification inspection (see 4.2).
b. Screening (see 4.3).
c. Conformance inspection (see 4.4).
4.2 Qualification inspection. Qualification inspection shall be in accordance with MIL-PRF-19500, and as specified
herein.
4.2.1 Group E qualification. Group E inspection shall be performed for qualification or re-qualification only. In
case qualification was awarded to a prior revision of the specification sheet that did not request the performance of
table II tests, the tests specified in table II herein that were not performed in the prior revision shall be performed on
the first inspection lot of this revision to maintain qualification.
4.3 Screening (JANTX and JANTXV levels only). Screening shall be in accordance with table E-IV of
MIL-PRF-19500, and as specified herein. The following measurements shall be made in accordance with table I
herein. Devices that exceed the limits of table I herein shall not be acceptable.
Measurement
Screen (see table E-IV
JANTX and JANTXV levels
9 and 10
Not applicable
11
ID(off)1, rds(on)1
12
See 4.3.1
13
Subgroup 2 of table I herein;
ĆID(off)1 = ±0.5 nA dc or ±100 percent of initial
value, whichever is greater.
Ćrds(on)1 = ±20 percent of initial value.
4.3.1 Power burn-in. Power burn-in conditions are in accordance with method 1039 of MIL-STD-750, condition A
and as follows: TA = +150°C; VGS = 24 V dc; VDS = 0.
4.4 Conformance inspection. Conformance inspection shall be in accordance with MIL-PRF-19500, and as
specified herein.
4.4.1 Group A inspection. Group A inspection shall be conducted in accordance with MIL-PRF-19500, and table I
herein.
4.4.2 Group B inspection. Group B inspection shall be conducted in accordance with the conditions specified for
subgroup testing in table E-VIB (JAN, JANTX, and JANTXV) of MIL-PRF-19500 and 4.4.2.1 herein. Electrical
measurements (end-points) shall be in accordance with table I, subgroup 2 herein.
6
