* TABLE I. Group A inspection - Continued.
Inspection 1/
MIL-STD-750
Symbol
Limits
Unit
Method
Conditions
Min
Max
3053
Load condition B;
Safe operating
*
(clamped inductive load)
area (switching)
(see figure 6);
TC = +25C;
Duty cycle 10 percent;
tp > 10 s; RS = 0.1 ohm;
RBB1 = 1;
VBB1 = 10 V dc max;
RBB2 = 20;
VBB2 = 4 V dc;
IC = 30 A dc;
VCC = 90 V dc (2N5671)
and 120 V dc (2N5672);
RL 3.0 (2N5671), 4.0
(2N5672);
L = 50 H, 0.1 ;
CR = 1N1186A;
Clamp voltage = 90 V dc +0, -5
(2N5671); 120 V dc +0, -5
(2N5672).
Device fails if clamp voltage is
not reached.
See table I, subgroup 2 herein
Electrical
measurements
Subgroups 6 and 7
Not applicable
1/
For sampling plan, see MIL-PRF-19500.
2/
This test required for the following end-point measurements only:
Group B, subgroups 3, 4, and 5 (JANS).
Group B, subgroups 2 and 3 (JAN, JANTX, and JANTXV).
Group C, subgroup 2 and 6.
Group E, subgroup 1.
