MIL-PRF-19500/507F
TABLE IV. Groups B, C, and E electrical measurements. 1/ 2/ 3/ 4/ 5/
Step
Inspection
Symbol
Limits 6/
Unit
Method
Conditions
Min
Max
µA
1.
Standby current
4016
DC method, VR = VWM
ID
Column 5
column 4 of table II
tp ≤ 300 ms, duty cycle ≤ 2
2.
Breakdown
4022
VBR
Column 2
Column 2
V
voltage
percent,
IBR = column 3 of table II
ĆID 6/
3.
Standby current
4016
DC method; VR = VWM
100 percent of
initial reading or
(column 4 of table II)
20 percent of
column 5 of table
II, whichever is
greater.
tp ≤ 300 ms, duty cycle ≤ 2
ĆVBR
4.
Breakdown
4022
± 5 percent of
voltage
initial value
6/
percent,
IBR = column 3 of table II
5.
Clamping voltage
tp = 1.0 ms (see 4.5.2.a);
VC
Column 6
V
IPP = column 7 of table II
1/ All electrical testing shall be performed twice, once in each direction.
2/ The electrical measurements for group B, table E-VIB (JAN, JANTX and JANTXV) of MIL-PRF-19500 are as
follows:
a. Subgroup 2, see table IV herein, steps 1 and 2.
b. Subgroup 6 see table IV herein, steps 1, 2, 3 and 4.
3/ The electrical measurements for group C, table E-VII of MIL-PRF-19500 are as follows:
a. Subgroup 2 and 3, see table IV herein, steps 1 and 2 for JAN,JANTX, and JANTXV.
b. Subgroup 9, see table IV herein, steps 1 and 2 for all levels.
4/ Column references are to table II.
5/ The electrical measurements for table E-IX of MIL-PRF-19500 are as follows: Subgroups 1, 2 and 8, see table IV
herein, steps 1 and 2.
6/ Devices which exceed the group A limits for this test shall not be accepted.
