MIL-PRF-19500/507F
3.7 Electrical test requirements. The electrical test requirements shall be the subgroups specified in table I
subgroup 2.
3.8 Workmanship. Semiconductor devices shall be processed in such a manner as to be uniform in quality and
shall be free from other defects that will affect life, serviceability, or appearance.
4. VERIFICATION
4.1 Classification of inspections. The inspection requirements specified herein are classified as follows:
a. Qualification inspection (see 4.2).
b. Screening (see 4.3).
c. Conformance inspection (see 4.4).
4.1.1 Sampling and inspection. Sampling and inspection shall be in accordance with MIL-PRF-19500, and as
specified herein except lot accumulation shall be 3-months in lieu of 6-weeks.
4.2 Qualification inspection. Qualification inspection shall be in accordance with MIL-PRF-19500 and as specified
herein.
4.2.1 Group E inspection. Group E inspection qualification shall be performed herein for qualification or
requalification only. In case qualification was awarded to a prior revision of the specification sheet that did not
request the performance of table III tests, the tests specified in table III herein that were not performed on the first
inspection lot to this revision to maintain qualification.
4.3 Screening (JANTX, and JANTXV levels only). Screening shall be in accordance with appendix E, table E-IV
of MIL-PRF-19500, and as specified herein. The following measurements shall be made in accordance with table I
herein. Devices that exceed the limits of table I herein shall not be acceptable.
Screen (see
Measurement
appendix E, table E-IV
of MIL-PRF-19500)
JANTX and JANTXV levels
T(high) = +175°C
3a
9, 10, 11
Not applicable
12
See 4.3.1
13
Interim electrical, delta, and group A, subgroups 2
and 3, electrical parameters not applicable for this
screen (performed in screen 12).
15
For JANTXV devices only 100 percent Inspection
will be in accordance with manufacturer's internal
failure criteria
4
