MIL-PRF-19500-507 Semiconductor Device, Diode, Silicon, Bipolar Transient Voltage Suppressor, Types 1N6036A Through 1N6072A Jan, Jantx, And JantxvThis specification covers the performance requirements for 1500 watt, bi-directional, silicon, transient voltage suppressor diodes. Three levels of product assurance are provided for each device as specified in MIL-PRF-19500.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15

MIL-PRF-19500/507F

DO-13

Dimensions

Symbol

Inches

Millimeters

Notes

1, 2

Min

Max

Min

Max

.215

.235

5.46

5.97

.293

.357

7.44

9.07

BLT

.570

14.48

.045

.100

1.14

2.54

.025

.035

0.64

0.89

1.000

1.625

25.40

41.28

.188

4.78

NOTES:

1. Dimensions are in inches.

2. Millimeter equivalents are given for general information only.

3. The major diameter is essentially constant along its length.

4. Within this zone, diameter may vary to allow for lead finishes and irregularities.

5. Dimension to allow for pinch or seal deformation anywhere along tubulation.

6. Symbol for bidirectional transient suppressor.

7. Lead 1 shall be electrically connected to the case.

8. In accordance with ASME Y14.5M, diameters are equivalent to φx symbology.

FIGURE 1. Physical dimensions (DO-13).
