MIL-PRF-19500/538G
TABLE I. Group A inspection - Continued.
MIL-STD-750
Limit
Symbol
Unit
Inspection 1/
Method
Conditions
Min
Max
Subgroup 5 - Continued
Test 2
(2N6676, 2N6678,
VCE = 30 V dc; IC = 5.9 A dc
2N6676T1, 2N6676T3,
2N6678T1, 2N6678T3)
Test 3
(All device types)
VCE = 100 V dc; IC = 0.25 A dc
Test 4
(2N6691, 2N6693)
VCE = 25 V dc; IC = 7 A dc
Test 5
(2N6676, 2N6678,
VCE = 300 V dc; IC = 20 mA dc
2N6676T1, 2N6676T3,
2N6678T1, 2N6678T3 )
VCE = 400 V dc; IC = 10 mA dc
(2N6691, 2N6693)
TA = +25°C, VCC = 15 V dc (see
Safe operating area
3053
(clamped switching)
figure 14 ); Load condition B, VBB2
= 5.0 V, RBB1 = 5 Ω; RBB2 = 1.5
Ω; L = 50 µH;
R of inductor = 0.05 Ω,
Rload =R of inductor
2N6676, 2N6676T1,
Clamp voltage = 350 V dc; IC = 15
2N6676T3, 2N6691
A dc
2N6678, 2N6678T1,
Clamp voltage = 450 V dc; IC = 15
2N6678T3, 2N6693
A dc
Electrical measurements
Table I, subgroup 2 herein.
Subgroup 6
Not applicable
Subgroup 7
1x109
Ω
Insulation resistance
1016
See 4.5.2
RISO
( 2N6676T1, 2N6676T3,
2N6678T1, 2N6678T3, 2N6691
and 2N6693 only)
1/ For sampling plan see MIL-PRF-19500.
