MIL-PRF-19500/547D

TABLE II. Group E inspection (all quality levels) for qualification or re-qualification only.

MIL-STD-750

Inspection

Sample

plan

Method

Conditions

Subgroup 1

45 devices

c=0

Temperature cycling

1051

Test condition G, 500 cycles.

Hermetic seal

1071

Fine leak

Gross leak

Electrical measurements

See table I, subgroup 2.

Subgroup 2

45 devices

c=0

Steady-state reverse bias

1042

Condition A, 1,000 hours.

Electrical measurements

See table I, subgroup 2.

Steady-state gate bias

1042

Condition B, 1,000 hours.

Electrical measurements

See table I, subgroup 2.

Subgroup 4

Sample size

N/A

Thermal impedance curves

See MIL-PRF-19500.

Subgroup 10

22 devices

c=0

Commutating diode for safe

3476

Test conditions shall be derived by the

operating area test procedure

manufacturer.

for measuring dv/dt during

reverse recovery of power

MOSFET transistors or

insulated gate bipolar

transistors
