The documentation and process conversion
INCH-POUND
measures necessary to comply with this revision
MIL-PRF-19500/550C
shall be completed by 18 January 2008.
18 October 2007
SUPERSEDING
MIL-PRF-19500/550B
20 October 1998
* PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, DIODE, SILICON, FAST-RECOVERY, HIGH CURRENT,
TYPES 1N6304, 1N6305, 1N6306, AND R TYPES,
JAN, JANTX, JANTXV, JANHC, AND JANKC
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
*
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for silicon, high efficiency, fast recovery,
switching power rectifier diodes. Three levels of product assurance are provided for each encapsulated device type
as specified in MIL-PRF-19500, and two levels of product assurance for each unencapsulated device type die.
1.2 Physical dimensions. See figure 1 (DO-203AB) formerly DO-5 and figures 2, 3, 4, and 5 for JANHC and
JANKC (die) dimensions.
* 1.3 Maximum ratings. Unless otherwise specified, TC = +25°C.
IR
TJ and
trr
VFM1
IFSM
Types
RθJC
VR
VRWM
IO
TSTG
TC = +55°C
at
IFM = 70 A (pk)
TC =
rated IR
+100°C
duty cycle
tp = 8.3 ms
≤ 2 percent
tp = 300 μs max
(1) (2)
μA dc
°C/W
V dc
A dc
ns
V (pk)
TC
A dc
V dc
1N6304, R
50
50
70
800
50
0.975
25
0.8
-65°C
100
100
70
800
50
0.975
25
0.8
1N6305, R
to
150
70
800
50
0.975
25
0.8
150
1N6306, R
+175°C
(1) Derate linearly, 875 mA/°C from TC = +100°C to +150°C, and 1,050 mA/°C above TC > +150°C.
(2) Higher IO, up to 1.2 times IO is allowable provided that appropriate heat sinking or forced air cooling maintains
the maximum junction temperature at or below +175°C as proven by the junction temperature rise time.
* Comments, suggestions, or questions on this document should be addressed to Defense Supply Center,
Columbus, ATTN: DSCC-VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to
Semiconductor@dscc.dla.mil . Since contact information can change, you may want to verify the currency of
this address information using the ASSIST Online database at https://assist.daps.dla.mil.
AMSC N/A
FSC 5961
