The documentation and process conversion
INCH-POUND
measures necessary to comply with this revision
MIL-PRF-19500/554E
shall be completed by 24 February 2010.
24 November 2009
SUPERSEDING
MIL-PRF-19500/554D
25 May 2006
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, DIODE, SILICON, SCHOTTKY BARRIER,
FAST RECOVERY, TYPE 1N6392, JAN, JANTX, JANTXV, AND JANHC
This specification is approved for use by the all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for a silicon, fast recovery, Schottky barrier
semiconductor diode. Three levels of product assurance are provided for each encapsulated device type as specified
in MIL-PRF-19500. One level of product assurance is provided for each unencapsulated device type.
1.2 Physical dimensions. See figure 1 (DO-5) and figure 2 (die).
1.3 Maximum ratings. Unless otherwise specified TA = 25°C.
VRRM and
VRSM
VR (1)
IFM (2)
IO (3)
IFSM
TJ
Type
Max
RΘJC
TC = +115°C
TC = +115°C
VRWM (1)
TSTG
°C/W
°C
V(pk)
V(pk)
V dc
A dc
A dc
A (pk)
1N6392
45
54
45
60
54
1,000
-55 to +175
1.0
(1) Full rated VRRM and VRWM is applicable over the range of TC = -55°C to + 173°C for IFM = 0. Full rated V
R is applicable over the temperature range of TC = -55°C to +166°C. When VR = 45 V dc and TC =
+166°C, then TJ = +175°C.
(2) Average current with a 50 percent duty cycle square wave including reverse amplitude equal to the
magnitude of full rated VRWM. Derate linearly at 1.09 A dc/°C for TC > +115°C.
(3) Average current with an applied sine wave peak value equal to the magnitude of full rated VRWM. For
temperature-current derating curves, see figure 3.
1.4 Unless otherwise noted, primary electrical characteristics at TC = +25°C.
Max VFM1
Max VFM3
Max IRM
Max CT
IFM = 120 A (pk)
VRM = 45 V (pk)
IFM = 10 A (pk)
VR = 5 V dc
Type
TJ = +25°C
TJ = +175°C
V (pk)
V (pk)
mA (pk)
mA (pk)
pF
1N6392
0.82
0.51
2.0
200
3,000
* Comments, suggestions, or questions on this document should be addressed to Defense Supply Center,
Columbus, ATTN: DSCC-VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to
Semiconductor@dscc.dla.mil. Since contact information can change, you may want to verify the currency of this
address information using the ASSIST Online database at https://assist.daps.dla.mil .
AMSC N/A
FSC 5961
