MIL-PRF-19500-556 Semiconductor Device, Field Effect Transistor, N-Channel, Silicon, Types 2N6782, 2N6782U, 2N6784, 2N6784U, 2N6786, And 2N6786U, Jan, Jantx, Jantxv, Jans, Janhc, And JankcThis specification covers the performance requirements for an N-channel, enhancement-mode, MOSFET, power transistor. Four levels of product assurance are provided for each encapsulated device type as specified in MIL-PRF-19500. Two levels of product assurance are provided for each unencapsulated device type.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14

MIL-PRF-19500/556L

Dimensions

Ltr.

Inches

Millimeters

Min

Max

Min

Max

.345

.360

8.76

9.14

.280

.295

7.11

7.49

.095

.115

2.41

2.92

LL1

.040

.055

1.02

1.40

LL2

.055

.065

1.40

1.65

.050 BSC

1.27 BSC

LS1

.025 BSC

0.635 BSC

LS2

.008 BSC

0.203 BSC

.020

.030

0.51

0.76

.105 REF

2.67 REF

.120 REF

3.05 REF

.045

.055

1.14

1.40

.070

.080

1.78

2.03

.120

.130

3.05

3.30

NOTES:

1. Dimensions are in inches.

2. Millimeters are given for general information only.

3. In accordance with ASME Y14.5M, diameters are equivalent to φx symbology.

4. Ceramic package only.

FIGURE 2. Physical dimensions for LCC.
