MIL-PRF-19500-556 Semiconductor Device, Field Effect Transistor, N-Channel, Silicon, Types 2N6782, 2N6782U, 2N6784, 2N6784U, 2N6786, And 2N6786U, Jan, Jantx, Jantxv, Jans, Janhc, And JankcThis specification covers the performance requirements for an N-channel, enhancement-mode, MOSFET, power transistor. Four levels of product assurance are provided for each encapsulated device type as specified in MIL-PRF-19500. Two levels of product assurance are provided for each unencapsulated device type.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14


MIL-PRF-19500/556L
2N6782, 2N6784, and 2N6786
Dimensions - 2N6782
Dimensions - 2N6784
Dimensions - 2N6786
Ltr
Inches
Millimeters
Inches
Millimeters
Inches
Millimeters
Min
Max
Min
Max
Min
Max
Min
Max
Min
Max
Min
Max
0.082
0.092
2.08
2.34
0.082
0.092
2.08
2.34
0.101
0.111
2.55
2.81
A
0.059
0.069
1.48
1.74
0.062
0.072
1.57
1.83
0.071
0.081
1.81
2.07
B
0.021
0.031
0.53
0.79
0.020
0.030
0.50
0.76
0.020
0.030
0.50
0.76
C
0.020
0.030
0.50
0.76
0.019
0.029
0.47
0.73
0.019
0.029
0.47
0.73
D
0.013
0.023
0.32
0.58
0.012
0.022
0.31
0.57
0.012
0.022
0.31
0.57
E
0.014
0.024
0.34
0.60
0.013
0.023
0.32
0.58
0.013
0.023
0.32
0.58
F
NOTES:
1.  Dimensions are in inches.
2.  Millimeters are given for general information only.
3.  Unless otherwise specified, tolerance is ±.005 inch (0.13 mm).
4.  The physical characteristics of the die are: The back metals are chromium, nickel, and silver and
the back contact is the drain. The top metal is aluminum.
5.  Die thickness is .0187 inch (0.475 mm) ±.0050 inch (0.130 mm).
FIGURE 3. JANHCA and JANKCA die dimensions.
5
