The documentation and process conversion measures
INCH-POUND
necessary to comply with this document shall be
MIL-PRF-19500/559K
completed by 23 July 2010.
23 April 2010
SUPERSEDING
MIL-PRF-19500/559J
20 April 2007
PERFORMANCE SPECIFICATION SHEET
* SEMICONDUCTOR DEVICE, UNITIZED, NPN, SILICON, SWITCHING,
FOUR TRANSISTOR ARRAY, TYPES 2N6989, 2N6989U, AND 2N6990,
JAN, JANTX, JANTXV, JANS, JANSM, JANSD, JANSP, JANSL, JANSR,
JANSF, JANSG, AND JANSH
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
* 1.1 Scope. This specification covers the performance requirements for NPN, silicon, switching transistors in a
four independent chip array. Four levels of product assurance are provided for each device type as specified in
MIL-PRF-19500. Provisions for radiation hardness assurance (RHA) to eight radiation levels is provided for JANS
product assurance levels. RHA level designators "M", "D", "P", "L", "R", "F', "G", and "H" are appended to the device
prefix to identify devices, which have passed RHA requirements.
1.2 Physical dimensions. See figure 1 (2N6989, dip), figure 2 (2N6990, flat), figure 3, (2N6989 and 2N6990,
14 pin dual-in-line), and figure 4 and figure 5 (2N6989U, 20 pin surface mount).
1.3 Maximum ratings unless otherwise specified TA = +25°C. (1)
*
VCBO
TJ
VEBO
VCEO
IC
RθJA
RθJA(AM)
Type
PT
PT
and
(4)
(4)
(4)
(3)
(3)
TA = +25°C
TA(AM) = +25°C
TSTG
(2)
(2)
°C/W
°C
°C/W
W
W
V dc
V dc
mA dc
V dc
2N6989
1.5
N/A
75
6
50
(2) 800
85
N/A
-65
To
1.0
2N6989U
N/A
75
6
50
(2) 800
160
N/A
+200
1.0
2N6990
N/A
75
6
50
(2) 800
175
N/A
N/A
2N6990
1.0
75
6
50
(2)800
N/A
23
Maximum voltage between transistors shall be ≥ 500 V dc.
(1)
(2)
For derating, see figures 6, 7, 8, and 9. Ratings apply to total package.
* (3)
For thermal impedance curves, see figures 10, 11, 12, and 13.
(4)
Ratings apply to each transistor in the array.
* Comments, suggestions, or questions on this document should be addressed to Defense Supply Center,
Columbus, ATTN: DSCC-VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to
Semiconductor@dscc.dla.mil. Since contact information can change, you may want to verify the currency of this
address information using the ASSIST Online database at https://assist.daps.dla.mil .
AMSC N/A
FSC 5961
