MIL-PRF-19500-559 Semiconductor Device, Unitized, Npn, Silicon, Switching, Four Transistor Array, Types 2N6989, 2N6989U, And 2N6990, Jan, Jantx, Jantxv, Jans, Jansm, Jansd, Jansp, Jansl, Jansr, Jansf, Jansg, And JanshThis specification covers the performance requirements for NPN, silicon, switching transistors in a four independent chip array. Four levels of product assurance are provided for each device type as specified in MIL-PRF-19500. Provisions for radiation hardness assurance \(RHA\) to eight radiation levels is provided for JANS product assurance levels. RHA level designators "M", "D", "P", "L", "R", "F", "G", and "H" are appended to the device prefix to identify devices, which have passed RHA requirements.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14

'ﾚﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄｿﾚﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄﾄｿ' by DLA - Page 8 of 31

MIL-PRF-19500/559K

PIN 1

INDEX

Symbol

Dimensions

Inches

Millimeters

Min

Max

Min

Max

.073

.085

1.85

2.16

.063

.075

1.60

1.91

.345

.355

8.76

9.02

.195

.205

4.95

5.21

.050 TYP

1.27 TYP

.070

.080

1.78

2.03

.025 REF

0.64 REF

.050 REF

1.27 REF

for pins 2 through 20

.080

.090

2.03

2.29

NOTES:

1. Dimensions are in inches.

2. Millimeters are given for general information only.

3. Unless otherwise specified, tolerance is ｱ.005 inch (0.13 mm).

4. In accordance with ASME Y14.5M, diameters are equivalent to φx symbology.

FIGURE 4. Physical dimensions for type 2N6989U.
