0 INCH-POUND
The documentation and process conversion measures
necessary to comply with this document shall be
MIL-PRF-19500/585K
completed by 28 September 2014.
28 June 2014
SUPERSEDING
MIL-PRF-19500/585J
21 November 2010
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, DIODE, SILICON, ULTRA-FAST RECOVERY, POWER RECTIFIER,
1N6620 THROUGH 1N6625, 1N6620U THROUGH 1N6625U, 1N6620US THROUGH 1N6625US,
JAN, JANTX, JANTXV, AND JANS
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of
this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for a silicon, ultra-fast recovery,
semiconductor power rectifier diode. Four levels of product assurance are provided for each device type as specified
in MIL-PRF-19500.
1.2 Physical dimensions. See figures 1 (similar to DO-41) and 2 (surface mount).
1.3 Maximum ratings. Unless otherwise specified, TA = +25C.
1.3.1 Ratings applicable to all types. Ratings applicable to all Part or Identifying Numbers (PIN). TSTG =
-65C to +175C, TJ = +150C maximum.
1.3.2 Ratings applicable to individual types.
Col. 1
Col. 2
Col. 3
Col. 4
Col. 5
Col. 6
Col. 7
Col. 8
Col. 9
Col. 10
IFSM
Device type
Barometric
RJL
RJX
RJEC
VRWM
IO(L)
IO2
trr
TA = +25C
at TL = +55C
pressure
at
(8)
at
L = .375 inch
max
L = .375 inch
(6)
tp = 8.3 ms
(9.52 mm)
(1) (4) (5)
(9.52 mm)
(7)
(1) (2) (3)
C/W
C/W
C/W
V dc
A
A
A pk
mm Hg
ns
1N6620, U, US
200
2.0
1.2
20
8
30
38
13
55
1N6621, U, US
400
2.0
1.2
20
8
30
38
13
55
1N6622, U, US
600
2.0
1.2
20
8
30
38
13
55
1N6623, U, US
800
1.5
1.0
20
33
50
38
13
55
1N6624, U, US
900
1.5
1.0
20
33
50
38
13
55
1N6625, U, US
1,000
1.5
1.0
15
33
60
38
13
55
See notes on next page.
