MIL-PRF-19500/603J

TABLE III. Group E inspection (all quality levels) for qualification or re-qualification only.

Qualification and

MIL-STD-750

Inspection

large lot quality

conformance

Method

Conditions

inspection

Subgroup 1

45 devices

c=0

Thermal shock

1051

Test condition G.

(temperature cycling)

Hermetic seal

1071

As applicable.

Fine leak

Gross leak

Electrical measurements

See table I, subgroup 2.

Subgroup 2 1/

45 devices

c=0

Steady-state gate bias

1042

Condition B, 1,000 hours.

Electrical measurements

See table I, subgroup 2.

Steady-state reverse bias

1042

Condition A, 1,000 hours.

Electrical measurements

See table I, subgroup 2.

Subgroup 4

Sample size

N/A

Thermal impedance curves

See MIL-PRF-19500.

Subgroup 5

3 devices

c=0

Test condition C. For device type

Barometric pressure

1001

2N7270, 2N7270U: VDS = 500 V; I(ISO)

(2N7270, 2N7270U only)

< 0.25 mA.

Subgroup 10

22 devices

c=0

Commutating diode for safe

3476

Test conditions shall be derived by the

operating area test procedure for

manufacturer.

measuring dv/dt during reverse

recovery of power MOSFET

transistors or insulated gate

bipolar transistors

A separate sample may be pulled for each test condition.
