MIL-PRF-19500-603 Semiconductor Device, Field Effect Radiation Hardened \(Total Dose Only\) Transistors, N-Channel, Silicon, Types 2N7268, 2N7269, 2N7270, 2N7394, 2N7268U, 2N7269U, 2N7270U, And 2N7394U, Jantxvr, F, G, H; Jansr, F, G, And HThis specification covers the performance requirements for an N-channel, enhancement-mode, MOSFET, radiation hardened \(total dose only\), power. Two levels of product assurance are provided for each device type specified in MIL-PRF-19500, with avalanche energy maximum rating \(EAS\) and maximum avalanche current \(IAS\). See 6.5 for JANHC and JANKC die versions.
