INCH-POUND
The documentation and process conversion
MIL-PRF-19500/608D
measures necessary to comply with this revision
24 August 2009
shall be completed by 24 November 2009.
SUPERSEDING
MIL-PRF-19500/608C
20 July 2007
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, DIODE, SILICON, SCHOTTKY, POWER RECTIFIER,
COMMON CATHODE, COMMON ANODE CENTER TAP, DOUBLER, TYPES 1N6660,
1N6660CCT1, 1N6660R, 1N6660CAT1, AND 1N6660DT1, JAN, JANTX, JANTXV, AND JANS
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for a silicon, schottky, power rectifier diodes.
Four levels of product assurance are provided for each device type as specified in MIL-PRF-19500.
1.2 Physical dimensions. See figure 1 (TO-254AA isolated).
1.3 Maximum ratings. TA = +25°C, unless otherwise indicated.
IFSM (1)
IO
RΘJC
RΘJC
TSTG
VRWM
VR
tp = 8.3 ms
(1) (2) (3)
Type
(1) (4)
(1) (4)
& TJ
(1)
(1)
TC = 100°C
TC = +25°C
Die 2
Die 1
°C/W
°C/W
°C
V
V
A dc
A(pk)
1N6660
45
45
15
300
1.65
1.65
1N6660CCT1
-65
to
1N6660R
45
45
15
300
2.8
2.8
+150
1N6660CAT1
1N6660DT1
45
45
15
300
2.8
1.65
(1)
Each individual diode.
(2)
For derating see figures 2 and 3.
(3)
Total package current is limited to 30 A dc.
(4)
For thermal impedance graphs see figures 4 and 5.
1.4 Primary electrical characteristics. RΘJC (entire package) = 0.85°C/W maximum for 1N6660CCT1. RΘJC
(entire package) = 1.5°C/W maximum for 1N6660CAT1 and 1N6660DT1. RΘJA = 50°C/W maximum, each individual
diode.
Comments, suggestions, or questions on this document should be addressed to Defense Supply Center,
Columbus, ATTN: DSCC-VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to
semiconductor@dscc.dla.mil . Since contact information can change, you may want to verify the currency of
this address information using the ASSIST Online database at https://assist.daps.dla.mil .
AMSC N/A
FSC 5961
