MIL-PRF-19500/608D
TABLE III. Group E inspection (all quality levels) for qualification and requalification only.
MIL-STD-750
Qualification
Inspection
Conditions
Method
Subgroup 1
Ttemperature cycling
n = 38, c = 0
1051
500 cycles
Hermetic seal
Electrical measurements
1071
See table II, steps 1 and 2
Subgroup 2
t = 1,000 hours, TC = +125°C; VR = 36 V dc
Steady-state blocking life
1048
n = 38, c = 0
Electrical measurements
See table II, steps 1, 2, and 3
Subgroup 3
Not applicable
Subgroup 4
Thermal impedance curves
3101
See MIL-PRF-19500
Subgroup 6
ESD
1020
n = 3, c = 0
Subgroup 10 1/
Condition A; TA = +25°C; IFSM = 300 A, 100 surges
Surge
4066
n = 22, c = 0
Electrical measurements
See table II, steps 1 and 2
1/ For each diode.
9
