MIL-PRF-19500/608D
10.0
D=0.5
D=0.4
1.0
D=0.3
D=0.2
D=0.1
Single Pulse
Notes:
(Thermal Resistance)
1. Duty Factor D = t1/t2
2. Peak TJ = PDM x ZΘJC + TC
0.1
0.0001
0.001
0.01
0.1
1
10
100
t1, RECTANGULAR PULSE DURATION (Sec)
* FIGURE 4. Thermal impedance for each leg 1N6660CAT1, 1N6660DT1, die 1, and 1N6660R.
10
D=0.5
1
D=0.4
D=0.3
D=0.2
Notes:
D=0.1
1. Duty Factor D = t1/t2
Single pulse
2. Peak TJ = PDM x ZΘJC + TC
(Thermal Resistance)
0.1
0.0001
0.001
0.01
0.1
1
10
t1, RECTANGULAR PULSE DURATION (Sec)
* FIGURE 5. Thermal impedance for each leg 1N6660CCT1, 1N6660DT1, die 2, and 1N6660.
12
