MIL-PRF-19500/616G
TABLE I. Group A inspection - Continued.
Inspection 1/
MIL-STD-750
Symbol
Limits
Unit
Method
Conditions
Min
Max
Subgroup 6
Mounting conditions in accordance
4066
Surge
with test method 1026 of
MIL-STD-750, TA = +25C,
IFSM = (see 1.3), IO = 0; VRM(w) = 0; six
surges; TA = 25C, tp = 8.3 ms, one
minute minimum time between surges.
Electrical
See table I, subgroup 2 herein.
measurements
Subgroup 7
Not applicable
1/ For sampling plan, see MIL-PRF-19500.
2/ The reverse breakdown characteristics shall be viewed on an oscilloscope with display calibration factors of 50 to
100 A/division and 20 to 50 V/division. Reverse current over the knee shall be at least 500 A. Each device
may exhibit a slightly rounded characteristic and any discontinuity or dynamic instability of the trace shall be cause
for rejection.
