INCH-POUND
The documentation and process conversion
measures necessary to comply with this revision
MIL-PRF-19500/620J
shall be completed by 28 May 2014.
28 February 2014
SUPERSEDING
MIL-PRF-19500/620H
25 August 2011
PERFORMANCE SPECIFICATION SHEET
SEMICONDUCTOR DEVICE, HERMETIC, DIODE, SILICON, RECTIFIER,
SCHOTTKY BARRIER, TYPES 1N5822, 1N5822US, 1N6864, 1N6864US,
JAN, JANTX, JANTXV, JANS, JANHC, AND JANKC
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification sheet and MIL-PRF-19500.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for silicon, Schottky barrier rectifier diodes.
Four levels of product assurance are provided for each device type as specified in MIL-PRF-19500, and two levels of
product assurance for die (element evaluation).
1.2 Physical dimensions. See figures 1 (axial), 2 (US surface mount), and 3 (die) dimensions.
* 1.3 Maximum ratings. Unless otherwise specified, TA = +25°C.
ZθJX
RθJL
RθJEC
VRWM
IO
IFSM
TSTG
TJ (1)
Types
(1) (2)
.375 inch
(1) (2)
(9.52 mm)
Lead length
°C
°C
°C/W
°C/W
°C/W
V(pk)
A dc
A(pk)
1N5822, 1N5822US
40
3.0
80
2.5
30
10
-65 to
-65 to
+150
+125
1N6864, 1N6864US
80
3.0
80
2.5
30
10
(1) See figures 4, 5, 6, and 7 for derating curves and for effects of VR on TJ. The maximum TJ depends on the
voltage applied. TA = +75°C for both axial and Metal Electrode Leadless Face diodes (MELF) (US) on printed
circuit board (PCB), PCB = FR4 - .0625 inch (1.59 mm) 1-layer 1-Oz Cu, horizontal, in still air, pads for (US) =
.061 inch (1.55 mm) x .105 inch (2.67 mm); pads for axial = .092 inch (2.34 mm) diameter, strip = .030 inch
(0.76 mm) x 1 inch (25.4 mm) long, lead length L ≤ .187 inch (≤ 4.75 mm); RΘJA with a defined PCB thermal
resistance condition included, is measured at IO = 1A.
(2) TA = 55°C for both axial and MELF (US) on printed circuit board (PCB), PCB = FR4 .0625 inch (1.59mm) pad;
area of each pad = .4 square inch (258.06 square mm).
Comments, suggestions, or questions on this document should be addressed to DLA Land and Maritime, ATTN:
VAC, P.O. Box 3990, Columbus, OH 43218-3990, or emailed to semiconductor@dla.mil . Since contact
information can change, you may want to verify the currency of this address information using the ASSIST
Online database at https://assist.dla.mil.
AMSC N/A
FSC 5961
