MIL-PRF-19500/620J
TEMPERATURE-CURRENT DERATING CURVE
Temper1N58re-CuEND-Ct DMratiTEDCurves
atu 22US rren AP eOUNng
1N5822 MELF Endcap Mounted
3.5
===================
Legend
(Top to Bottom)
3
===================
Vr=10V
Vr=20V
2.5
Vr=30V
Vr=40V
2
1.5
1
0.5
0
25
50
75
100
125
150
175
Sinewave Operation 50% Duty Cycle
TECc °(C) ) End Cap)p)
Te ( ēC ( (End Ca
Sinewave Operation 50% Duty Cycle
Thermal Resistance Junction to End Cap = 10.0ēC/W
RθJEC = 10.0°C/W
NOTES:
1. This is the true inverse of the worst case thermal resistance value. All devices are capable of operating ≤ TJ
specified on this curve. Any parallel line to this curve will intersect the appropriate power for the desired
maximum TJ allowed.
2. This temperature-current derating curve varies with applied voltage.
FIGURE 5. Temperature current derating for 1N5822US.
13
