MIL-PRF-19500/118L
TABLE II. Group E inspection (all quality levels) for qualification and requalification only.
Qualification
MIL-STD-750
inspection
Inspection
Method
Conditions
Subgroup 1
n = 45, c = 0
100 cycles 0C to +100C
Thermal shock (glass
1056
strain)
500 cycles, -65C to +175C
Temperature cycling
1051
Hermetic seal
1071
Gross leak.
Electrical measurement
See table I, subgroup 2
Subgroup 2
Intermittent operating life
1037
10,000 cycles; IF = 200 mA (DC or average rectified
current), ton = toff = 1 minute.
Electrical measurements
See table I, subgroup 2
Subgroup 4
Thermal impedance curves
See MIL-PRF-19500, table E-IX, group E, subgroup 4.
Subgroup 5
Not applicable
Subgroup 9
1057
Test condition B. Test until failure occurs or to a
n = 45
Resistance to glass
maximum of 25 cycles, whichever comes first
cracking
Subgroup 10
Monitored mission
1055
n = 22, c = 0
temperature cycling
Electrical measurements
See table I, subgroup 2
12
